Choose a Frame, Circumference and Work Load Rating

N&K Dip Net Frames :

– Custom made from lightweight, yet strong 6061-T6 aluminum.

Р Double and triple reinforced frames.

Р Incredible strength and superior lightweight performance.

– Heavy-duty fitted polyethylene net guard comes standard
on all N&K Dip Nets frames.

1. Choose a frame shape.

A. Trapezoid

B. Narrow Trapezoid

C. Square Corner Rectangle

D. Round Corner Rectangle

E. Oval

2. Choose a frame circumference.

3. Choose a work load rating.

A. Light Work Load

B. Medium Work Load

C. Heavy Work Load

4. Lift Bar

Optional on all 55″, 73″, 80″, 101″

frame circumferences.

5/8″ cross horizontal lifting

handle creates a lifting point

near center of gravity.

Part Number . . . . . . . . . . . LB58

Not available for frames to be used

for electro-shocking applications.

FRAME STYLE – SQUARE CORNER RECTANGLE

FRAME

CIRCUMFERENCE

PART NUMBER FRONT WIDTH FULL LENGTH
LIGHT
WORK LOAD
MEDIUM WORK LOAD HEAVY
WORK LOAD
28″ R228L N/A N/A 10″ 7″
35″ R235L R235M N/A 12″ 8.5″
47″ R247L R247M N/A 16″ 10.5″
55″ N/A R255M R255H 17.5″ 16″
73″ N/A N/A R273H 24.5″ 17.5″
80″ N/A N/A R280H 25″ 21
101″ N/A N/A R2101H 23″ 23″
Special Order RSOL R2S0M R2S0H

Lift Bar………………………………………….Part Number LB58

Optional on all 55″, 73″, 80″, 101″ frame circumferences

FRAME STYLE – ROUND CORNER RECTANGLE

FRAME

CIRCUMFERENCE

PART NUMBER FRONT WIDTH FULL LENGTH
LIGHT
WORK LOAD
MEDIUM WORK LOAD HEAVY
WORK LOAD
55″ N/A R655M R655H 18″ 17.5″
101″ N/A N/A R6101H 32″ 28″
Special Order N/A R6S0M R6S0H

Lift Bar……………………………………….Part Number LB58

Optional on all 55″, 73″, 80″, 101″ frame circumferences

FRAME STYLE – OVAL

FRAME

CIRCUMFERENCE

PART NUMBER FRONT WIDTH FULL LENGTH
LIGHT
WORK LOAD
MEDIUM WORK LOAD HEAVY
WORK LOAD
35″ O35L O35M N/A 10″ 13″
47″ Narrow NO47L NO47M N/A 12″ 18″
47″ Wide WO47L WO47M N/A 13.5″ 16.5″
73″ N/A N/A O73H 19″ 26″
Special Order R2S0L R2S0M R2S0H

Lift Bar…………………………………………Part Number LB58

Optional on all 55″, 73″, 80″, 101″ frame circumferences
